Granite Gang Saw Machine

Granite Gang Saw Machine
Granite Gang Saw Machine
Product Code : A-16
Brand Name : Arunodaya Foundries
Product Description

We have carved a niche in the industry by involving ourselves in manufacturing, supplying and exporting tough built Granite Gang Saw Machine. In order to attain complete customer satisfaction, this machine is manufactured using high grade stainless steel and other components that are sourced from certified vendors of the market. This machine is extensively used for engineering and industrial cutting & grinding purposes. As per the needs of clients, this Granite Gang Saw Machine is made available in various sizes, models and specifications.

This machine is highly appreciated for:

  • Excellent sawing performance

  • Corrosion resistant

  • Rugged construction

  • Simple usage

Other details:

The Granite sawing machine, working with slurry and steel shots, is in principle similar to conventional Gang saw machine, used for marble sawing.

Technical Specifications

SPECIFICATIONS

Block Size

3 x 3 x 2 m

No. of blades

120

Requirement of steel shots

4.2 kg/sq. meter

Total load

115 H.P.

App. Weight of machine

42000 kg.

Overall space required

17 x 7 x 6 m

Size of the Machine

3.15 x 3 x 2 M

Strainers

120

Tensioning Device

Mechanical

Minimum slab thickness

20 mm

No. of strokes

85 RPM

Run of blades

400 mm

Saw Car

3150 x 3000

Spacers

240

Main Motor

50 H.P.

Abrasive Lift Pump

30 H.P.

Short supply Motor

0.75 H.P.

Lime mixing tank Motor

2 H.P.

Slurry Spinkler Motor

2 H.P.

Lubrication Pump Motor

1 H.P.

Feeding

Automatic with 2 H.P.D.C.

Fast up & down Motor

10 H.P.

Electric control panel

Fitted with necessary controls & safety device

Water requirement

30 lit/min

Blade section

120 x 4.2 to 4.5 mm

Thickness of cut

7.2 mm

Vertical sawing capacity of one blade

2 to 3 m

Tension per blade

5.0 ton

Consumption per sq. meter

1.8 to 2 Kg Approx.

Type of Grit

Angular steel

Size of grain

0.8 to 1 mm

Consumption per sq.m

10 to 13 Kg Approx
